Split AC Removal Guide

Removing a split air conditioner requires skill, care, and the right tools to ensure no damage is done to the unit or surrounding property. This guide outlines the step-by-step process for safe and efficient split AC removal.

---

Step 1: Switch Off Power Supply

Before beginning the removal process:

• Turn off the power supply from the main electrical panel.

• Unplug or disconnect the AC’s power source to avoid electrical hazards.

⚠️ Safety First: Never start removal with the unit still connected to electricity.

---

Step 2: Recover Refrigerant Gas

• Use a recovery machine and manifold gauge set to safely collect the refrigerant gas from the AC system.

• Store the gas in an approved recovery cylinder for future use or disposal.

💡 Note: Refrigerant must be recovered legally and safely by a certified technician to avoid environmental harm or legal penalties.

---

Step 3: Disconnect Electrical Wiring

• Carefully open the connection panel on the indoor and outdoor units.

• Label and remove the electrical wires to avoid confusion during re-installation.

🔧 Tip: Take a photo of the wiring setup before disconnection for easy reference.

---

Step 4: Disconnect Copper Refrigerant Pipes

• Using proper wrenches, disconnect the copper lines (suction and discharge) from both the indoor and outdoor units.

• Seal the open pipe ends with rubber caps or tape to prevent dirt or moisture from entering.

📌 Caution: Use pipe cutters if necessary—never bend or crack the pipes.

---

Step 5: Remove the Indoor Unit

• Detach the drain pipe and carefully lift the indoor unit from the mounting bracket.

• Ensure no water spills during this process.

🛠️ Use assistance if needed: Indoor units can be bulky and delicate.

---

Step 6: Remove the Mounting Plate

• Unscrew and remove the wall-mounted bracket that held the indoor unit.

• Patch any holes left in the wall if required.

---

Step 7: Remove the Outdoor Unit

• Carefully lift the outdoor unit from its base or stand.

• Disconnect any mounting bolts or support brackets.

• Use proper lifting tools or a helper to move the heavy unit safely.

⚙️ Pro Tip: Check for any residual refrigerant leaks before final storage or transport.

---

Step 8: Organize and Pack Components

• Coil and pack copper pipes, wiring, and the drain hose.

• Clean both indoor and outdoor units if they are being re-installed elsewhere.

• Store all components securely to avoid damage during transportation.

---

✅ Split AC Removal Complete!

Once removed, your AC is ready for relocation, storage, or reinstallation. Always have AC removal done by a trained professional to ensure safety and compliance with environmental regulations.
